Pergolino Pergolas

The Pergolino by STOBAG in Vancouver is our most robust retractable pergola system, engineered in Switzerland to provide reliable shade and rain protection for large patios and commercial terraces.

​

I. Technical Specifications & Limits

Designed for expansive outdoor living, the

pergolino covers areas that standard folding-arm awnings cannot.

​

• Maximum Width: Up to 700 cm (23' 0") in a single unit.

• Maximum Projection: Up to 600 cm (19' 8").

• Wind Resistance: Engineered to withstand up to Beaufort 6 (approx. 49 km/h), depending on dimensions.

• Rain Suitability: Suitable for use in rain with a minimum pitch of 8° to 17° (depending on model) and specialized water-repellent fabrics.

  ​

II. Advanced System Features

• Stoblock™ Technology: A patented auto-mechanical locking system that automatically tensions the fabric when fully extended, preventing sagging and ensuring water run-off.

• Integrated Gas Springs: High-pressure gas-filled cylinders built into the guide rails maintain constant fabric tension in any position.

• Water Management: Features an integrated water duct in the front profile for lateral rainwater drainage.

• Versatile Mounting: Adjustable sliding brackets and guide rails allow for flexible installation on walls, ceilings, or even existing pergola structures.

  ​

III. Premium Comfort Options

• Tunable White LED Lighting: Dimmable LED strips can be integrated directly into the guide rails or cross-tubes to create the perfect evening ambiance.

• Volant-Plus Valance: An optional drop-down front screen (up to 170cm height) for additional privacy and protection from low-lying sun.

• Fabric Selection: Choose from specialized waterproof polyester or high-tensile acrylic fabrics from the STOBAG collection.

• Foundation Options: Supports can be fixed via floor sleeves, footplates, or even weighted flower troughs for a non-permanent installation.

  ​

IV. Ideal Applications

• Hospitality: Create a dry, sun-protected terrace for restaurant guests, regardless of the weather.

• Modern Residences: A sleek alternative to fixed pergolas that may not fit a contemporary home's aesthetic.

• Large Decks: Ideal for coastal or windy areas where a standard awning would be too vulnerable.

  ​

Custom Engineering for Your Space: Every STOBAG PERGOLINO

 is custom-manufactured to your exact measurements.





​
